前言

我的飞牛OS的某一块硬盘仅512G大小，并将全部容量设置为Basic存储模式，而最近我找了一块1T的新硬盘，希望能替代旧硬盘并扩容硬盘。以下是我的踩坑记录。

下文中设备的路径等请改成自己实际的路径，千万不要照抄！

复制数据

先关闭飞牛OS并取出硬盘，并在Windows系统下使用DiskGenius软件中的“克隆磁盘”功能将旧硬盘的所有数据拷贝到新硬盘中。我使用的是“复制所有扇区”。完成后，我将新硬盘放入飞牛OS所在的机器中，然后打开飞牛OS。

扩容分区

此时打开飞牛OS的设置界面，我们可以看到新硬盘已经成功代替了旧硬盘。不过此时只有新硬盘的前500G在使用，而剩余的500G则处于空闲状态。我们需要把剩余的500G也扩充到前面的存储分区去。

我在测试时，没有卸载掉这个硬盘，最终也成功了，但是个人不建议这么做。

首先，我们通过SSH连接我们的飞牛OS。然后使用sudo fdisk -l看一下此时的分区情况。

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
denvo@denvosCenterm:~$ sudo fdisk -l
[sudo] password for denvo:
Disk /dev/sda: 29.82 GiB, 32017047552 bytes, 62533296 sectors
Disk model: SSD 32GB
Units: sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 512 bytes
I/O size (minimum/optimal): 512 bytes / 512 bytes
Disklabel type: dos
Disk identifier: 0x1372dc16

Device     Boot    Start      End  Sectors  Size Id Type
/dev/sda1           2048   194559   192512   94M 83 Linux
/dev/sda2         194560 52428799 52234240 24.9G 83 Linux
/dev/sda3       52428800 62531583 10102784  4.8G 83 Linux


Disk /dev/sdb: 931.51 GiB, 1000204886016 bytes, 1953525168 sectors
Disk model: Tech
Units: sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 4096 bytes
I/O size (minimum/optimal): 4096 bytes / 4096 bytes
Disklabel type: gpt
Disk identifier: F6C0FF81-599B-430E-A54F-8038DBB7030D

Device     Start       End   Sectors   Size Type
/dev/sdb1   2048 976773119 976771072 465.8G Linux RAID


Disk /dev/md0: 465.63 GiB, 499971522560 bytes, 976506880 sectors
Units: sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 4096 bytes
I/O size (minimum/optimal): 4096 bytes / 4096 bytes


Disk /dev/mapper/trim_d014f486_5dff_41db_a333_eae448374f08-0: 465.63 GiB, 499969425408 bytes, 976502784 sectors
Units: sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 4096 bytes
I/O size (minimum/optimal): 4096 bytes / 4096 bytes
denvo@denvosCenterm:~$

根据输出，我这里的实际内容应该是存储在/dev/sdb1里的，但是我们发现后面竟然有Linux RAID的标识。说实话我没有想到，毕竟我之前创建的存储分区使用的是Basic模式，并没有使用任何Raid。然后，输出中竟然还有一个/dev/md0的设备，为什么呢？我们输入sudo mdadm -D /dev/md0，得到如下结果。

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
denvo@denvosCenterm:~$ sudo mdadm -D /dev/md0
/dev/md0:
           Version : 1.2
     Creation Time : Sun Mar  9 22:27:25 2025
        Raid Level : raid1
        Array Size : 488253440 (465.63 GiB 499.97 GB)
     Used Dev Size : 488253440 (465.63 GiB 499.97 GB)
      Raid Devices : 1
     Total Devices : 1
       Persistence : Superblock is persistent

     Intent Bitmap : Internal

       Update Time : Sun Jun 22 17:46:13 2025
             State : clean
    Active Devices : 1
   Working Devices : 1
    Failed Devices : 0
     Spare Devices : 0

Consistency Policy : bitmap

              Name : denvosCenterm:0  (local to host denvosCenterm)
              UUID : 6de584a8:dee738cb:aa33a826:be3fdf5d
            Events : 32

    Number   Major   Minor   RaidDevice State
       0       8       17        0      active sync   /dev/sdb1
denvo@denvosCenterm:~$

竟然使用的是Raid1？好吧，看来大概的情况是飞牛OS把这个单块硬盘整了个Raid1，然后把这个Raid映射到了/dev/mapper/trim_d014f486_5dff_41db_a333_eae448374f08-0中并使用Brtfs文件系统。好了，既然如此，那就有大概的思路了。首先我们需要确保刚才sudo mdadm -D /dev/md0得到的结果中State一项对应的值为clean，然后我们继续操作。

我们首先来对新硬盘中的分区进行扩容。我这个硬盘是GPT格式的，所以这么扩容：

我们使用sudo parted /dev/sdb命令进入目标硬盘的设置，然后输入print all找到我们需要扩容的分区的序号。

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
denvo@denvosCenterm:~$ sudo parted /dev/sdb
GNU Parted 3.5
Using /dev/sdb
Welcome to GNU Parted! Type 'help' to view a list of commands.
(parted) print all
Model: JMicron Tech (scsi)
Disk /dev/sdb: 1000GB
Sector size (logical/physical): 512B/4096B
Partition Table: gpt
Disk Flags:

Number  Start   End    Size   File system  Name     Flags
 1      1049kB  500GB  500GB               primary  raid


Model: ATA SSD 32GB (scsi)
Disk /dev/sda: 32.0GB
Sector size (logical/physical): 512B/512B
Partition Table: msdos
Disk Flags:

Number  Start   End     Size    Type     File system  Flags
 1      1049kB  99.6MB  98.6MB  primary  ext4
 2      99.6MB  26.8GB  26.7GB  primary  ext4
 3      26.8GB  32.0GB  5173MB  primary


Model: Linux device-mapper (linear) (dm)
Disk /dev/mapper/trim_d014f486_5dff_41db_a333_eae448374f08-0: 500GB
Sector size (logical/physical): 512B/4096B
Partition Table: loop
Disk Flags:

Number  Start  End    Size   File system  Flags
 1      0.00B  500GB  500GB  btrfs


Error: /dev/md0: unrecognised disk label
Model: Linux Software RAID Array (md)
Disk /dev/md0: 500GB
Sector size (logical/physical): 512B/4096B
Partition Table: unknown
Disk Flags:

(parted)

我这里对应的序号是1，所以我现在输入resizepart 1 100%，将硬盘内序号为1的分区大小调整至100%。然后输入quit退出。

1
2
3
4
5
(parted) resizepart 1 100%
(parted) quit
Information: You may need to update /etc/fstab.

denvo@denvosCenterm:~$

对于MBR格式的硬盘，请使用sudo fdisk /dev/sdX来扩展分区。最后达到的效果需一样。

此时的分区状态像这样
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
denvo@denvosCenterm:~$ sudo fdisk -l
Disk /dev/sda: 29.82 GiB, 32017047552 bytes, 62533296 sectors
Disk model: SSD 32GB
Units: sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 512 bytes
I/O size (minimum/optimal): 512 bytes / 512 bytes
Disklabel type: dos
Disk identifier: 0x1372dc16

Device     Boot    Start      End  Sectors  Size Id Type
/dev/sda1           2048   194559   192512   94M 83 Linux
/dev/sda2         194560 52428799 52234240 24.9G 83 Linux
/dev/sda3       52428800 62531583 10102784  4.8G 83 Linux


Disk /dev/sdb: 931.51 GiB, 1000204886016 bytes, 1953525168 sectors
Disk model: Tech
Units: sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 4096 bytes
I/O size (minimum/optimal): 4096 bytes / 4096 bytes
Disklabel type: gpt
Disk identifier: F6C0FF81-599B-430E-A54F-8038DBB7030D

Device     Start        End    Sectors   Size Type
/dev/sdb1   2048 1953525134 1953523087 931.5G Linux RAID


Disk /dev/md0: 465.63 GiB, 499971522560 bytes, 976506880 sectors
Units: sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 4096 bytes
I/O size (minimum/optimal): 4096 bytes / 4096 bytes


Disk /dev/mapper/trim_d014f486_5dff_41db_a333_eae448374f08-0: 465.63 GiB, 499969425408 bytes, 976502784 sectors
Units: sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 4096 bytes
I/O size (minimum/optimal): 4096 bytes / 4096 bytes
denvo@denvosCenterm:~$

接下来我们需要扩展Raid上的记录，使用sudo mdadm --grow /dev/md0 --size=max。

1
2
3
denvo@denvosCenterm:~$ sudo mdadm --grow /dev/md0 --size=max
mdadm: component size of /dev/md0 has been set to 976629447K
denvo@denvosCenterm:~$
此时的分区状态像这样
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
denvo@denvosCenterm:~$ sudo fdisk -l
Disk /dev/sda: 29.82 GiB, 32017047552 bytes, 62533296 sectors
Disk model: SSD 32GB
Units: sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 512 bytes
I/O size (minimum/optimal): 512 bytes / 512 bytes
Disklabel type: dos
Disk identifier: 0x1372dc16

Device     Boot    Start      End  Sectors  Size Id Type
/dev/sda1           2048   194559   192512   94M 83 Linux
/dev/sda2         194560 52428799 52234240 24.9G 83 Linux
/dev/sda3       52428800 62531583 10102784  4.8G 83 Linux


Disk /dev/sdb: 931.51 GiB, 1000204886016 bytes, 1953525168 sectors
Disk model: Tech
Units: sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 4096 bytes
I/O size (minimum/optimal): 4096 bytes / 4096 bytes
Disklabel type: gpt
Disk identifier: F6C0FF81-599B-430E-A54F-8038DBB7030D

Device     Start        End    Sectors   Size Type
/dev/sdb1   2048 1953525134 1953523087 931.5G Linux RAID


Disk /dev/md0: 931.39 GiB, 1000068554240 bytes, 1953258895 sectors
Units: sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 4096 bytes
I/O size (minimum/optimal): 4096 bytes / 4096 bytes


Disk /dev/mapper/trim_d014f486_5dff_41db_a333_eae448374f08-0: 465.63 GiB, 499969425408 bytes, 976502784 sectors
Units: sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 4096 bytes
I/O size (minimum/optimal): 4096 bytes / 4096 bytes
denvo@denvosCenterm:~$

接下来更新物理卷和逻辑卷，然后扩展Brtfs文件系统。根据如下进行设置。

1
2
3
4
5
6
7
8
9
denvo@denvosCenterm:~$ sudo pvresize /dev/md0
  Physical volume "/dev/md0" changed
  1 physical volume(s) resized or updated / 0 physical volume(s) not resized
denvo@denvosCenterm:~$ sudo lvextend -l +100%FREE /dev/mapper/trim_d014f486_5dff_41db_a333_eae448374f08-0
  Size of logical volume trim_d014f486_5dff_41db_a333_eae448374f08/0 changed from 465.63 GiB (119202 extents) to 931.38 GiB (238434 extents).
  Logical volume trim_d014f486_5dff_41db_a333_eae448374f08/0 successfully resized.
denvo@denvosCenterm:~$ sudo btrfs filesystem resize max /vol1
Resize device id 1 (/dev/mapper/trim_d014f486_5dff_41db_a333_eae448374f08-0) from 465.63GiB to max
denvo@denvosCenterm:~$

第二条命令中，/dev/mapper/trim_d014f486_5dff_41db_a333_eae448374f08-0是Raid最终映射到的位置；第三条命令中，/vol1是实际挂载点。

扩充结果

完成后，现在我们来看看分区情况：

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
denvo@denvosCenterm:~$ sudo fdisk -l
Disk /dev/sda: 29.82 GiB, 32017047552 bytes, 62533296 sectors
Disk model: SSD 32GB
Units: sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 512 bytes
I/O size (minimum/optimal): 512 bytes / 512 bytes
Disklabel type: dos
Disk identifier: 0x1372dc16

Device     Boot    Start      End  Sectors  Size Id Type
/dev/sda1           2048   194559   192512   94M 83 Linux
/dev/sda2         194560 52428799 52234240 24.9G 83 Linux
/dev/sda3       52428800 62531583 10102784  4.8G 83 Linux


Disk /dev/sdb: 931.51 GiB, 1000204886016 bytes, 1953525168 sectors
Disk model: Tech
Units: sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 4096 bytes
I/O size (minimum/optimal): 4096 bytes / 4096 bytes
Disklabel type: gpt
Disk identifier: F6C0FF81-599B-430E-A54F-8038DBB7030D

Device     Start        End    Sectors   Size Type
/dev/sdb1   2048 1953525134 1953523087 931.5G Linux RAID


Disk /dev/md0: 931.39 GiB, 1000068554240 bytes, 1953258895 sectors
Units: sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 4096 bytes
I/O size (minimum/optimal): 4096 bytes / 4096 bytes


Disk /dev/mapper/trim_d014f486_5dff_41db_a333_eae448374f08-0: 931.38 GiB, 1000064679936 bytes, 1953251328 sectors
Units: sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 4096 bytes
I/O size (minimum/optimal): 4096 bytes / 4096 bytes
denvo@denvosCenterm:~$ df -h
Filesystem                                               Size  Used Avail Use% Mounted on
udev                                                     1.9G     0  1.9G   0% /dev
tmpfs                                                    383M   39M  344M  11% /run
/dev/sda2                                                 25G   11G   13G  44% /
tmpfs                                                    1.9G  1.4M  1.9G   1% /dev/shm
tmpfs                                                    5.0M     0  5.0M   0% /run/lock
trimafs                                                  932G   65G  866G   7% /fs
/dev/mapper/trim_d014f486_5dff_41db_a333_eae448374f08-0  932G   65G  866G   7% /vol1
1000-1-8543a4d8{SYtpW}:cloud-storage/v1/dav              1.0P     0  1.0P   0% /vol02/1000-1-8543a4d8
1000-1-dba14728{2_a9I}:cloud-storage/v1/dav              1.0P     0  1.0P   0% /vol02/1000-1-dba14728
overlay                                                  932G   65G  866G   7% /vol1/docker/overlay2/c931c52cd06181098eff1309a7e772abe2e4cd2979dc40613d8e96145f5b495f/merged
tmpfs                                                    383M     0  383M   0% /run/user/1000
denvo@denvosCenterm:~$

看样子已经成功了。此时我们重新打开飞牛OS的设置界面，刷新后发现我们的存储空间已经成功扩展。

参考

gerchart的博客
ChatGPT

  • 标题: 飞牛OS扩容Basic硬盘
  • 作者: Denvo
  • 创建于 : 2025-06-22 19:49:53
  • 更新于 : 2026-01-25 17:29:40
  • 链接: https://www.denvoshome.xyz/posts/FnOS-enlargeBasicStorage/
  • 版权声明: 本文章采用 CC BY-SA 4.0 进行许可。
评论
目录
飞牛OS扩容Basic硬盘
  1. 1. 前言
  2. 2. 复制数据
  3. 3. 扩容分区
  4. 4. 扩充结果
